DASCOM DC-7600 Kartendrucker USB ETH DUO, 28.836.0090

DASCOM DC-7600 Kartendrucker USB ETH DUO,  28.836.0090

DC-7600

The ReTransfer printing technology of the DASCOM DC-7600 is the next level of Direct-To-Card print technology. First, the image is printed onto a film, then transferred from the film to the card. This technique is suitable for Over-the-Edge and heavy duty printing, improves reliability and thus suitable for a vast variety of card types for all professional industries.

Industrial and commercial grade design

High resolution printing with 600 dpi

High speed printing resulting to high productivity

Over-the-edge full card printing

High-capacity card feeder

Parameter

Printing Method

Color dye sublimation retransfer

Resolution

600 DPI

Printing Capability

Single side, double side, over-the-edge, photo quality image color

Printing Speed

Single side 144 cards per hour (CPH), dual side 95 CPH

Card Thickness

20-50 mil thickness; 20-50 mil through manual slot

Dimensions

12.25" (L) x 13.25" (W) x 17" (H)

Card Capacity

250 cards (30 mil thickness), manual feed: 1 card

Interface

USB 2.0; Ethernet 10/100; Optional USB 3.0 and WI-FI

DC-7600

 TECHNICAL DATA

 Print Method  Colour dye sublimation retransfer technology

 Resolution  600 dpi

 Print Capability Single Side, Double Side, Over-the-Edge, photo quality image colour

 Print Speed Single Side: 25 sec.

 Double Side: 55 sec.

 Lifetime Print Head 100.000 cards

 Interfaces  USB (2.0), Ethernet (10/100)

 Card Thickness 0,5 - 1,25 mm (20 - 50 mil)

 Security Features  RFID ribbon, card feeder lock, custom watermarks (BMP)

 Card Loading Auto card feeder for 250 cards (0,76 mm thickness)

 Manual feed: single card

 Card Types PVC, ABS, PET, PET-G, PC

 85,6 x 53,98 mm (ISO ID-1/CR-80 size)

 Consumables  Ribbon YMCK (500 Images), Ribbon YMCKH (400 Images),

 Ribbon YMCKK (400 Images), Transfer Film YMCK (500 Images)

 Ribbon K (500 Images), Transfer Film K (500 Images)

 Cleaning Set Cleaning Card

 Cleaning Roller

 Physical Weight  22 kg

 Physical Size 339 x 311 x 431 mm (W x D x H)

 Power Voltage  Auto wide ranging, 100 - 240 V AC - 50/60 Hz

 Environment  Printing: +15° to +30° C Temperature; 35 - 95% Humidity

 Storage: +5° C to +45° C Temperature; 35 - 95% Humidity

 Driver Windows 8/8.1/10/11 and Server 2012/2016/2019/2022

 Optional Encoder Encoder for MIFARE
